3-Point Chipper & Shredder
3″ x 5″ chipping capacity; 1″ shredding capacity
Changeable shredder grate, 1 1/2″ (normal) and 3/4″ (fine).
Twenty four 1/3″ thick free-swinging hammers pulverize brush.
Large, low-profile hopper for easy filling.
13″ diameter 0.6″ Thick flywheel with 2 reversible 1/3″ thick tool grade steel chipping knifes quickly eat branches.
2 Year warranty / 4 year optional
Weight: 540 lbs shipped, 470 lbs net
Powered by：
Tractor PTO
15-50 HP
Use-ECO19
ECO’s have bigger blades, a larger flywheel, larger shredders and larger feed chutes than comparable units. This provides more shredding and chipping efficiency.
Features-ECO19
Features:
• 3″ x 5″ chipping capacity; 1″ shredding capacity
• Changeable shredder grate, 1 1/2″ (normal) and 3/4″ (fine)
• Twenty four 1/3″ thick free-swinging hammers pulverize brush
• Large, low-profile hopper for easy filling
• 13″ diameter 0.6″ Thick flywheel with 2 reversible 1/3″ thick tool grade steel chipping knifes quickly eat branches
• 1 Year warranty
• Weight: 540 lbs shippe,d 470 lbs net
Technica data:
• For minimum 22 HP tractors (16 kW)
• Cutting knives: 2
• Hammers: 24
• Wood max diametre: 8 cm
• Double hopper
• 3-point hitch of cat.I
• Cast iron gearbox with free wheel
Selling point:
• 3″ capacity wood chipper
• Adjustable stand allows feed height to be changed
• Changeable Shredder Grate to control output size
• Only requries 15 Hp PTO tractor
• 24 heavy 1/3″ hammers pulverize brush, leaves, corn stocks, etc.
• PTO Powered
